The Sukup Bucket Elevator is engineered to provide efficient and reliable material handling. Its design incorporates features to minimize product damage, providing gentle handling of materials. The elevator design features a low-impact head design, allowing the product to slide gently along the contour of the hood, reducing the risk of damage.
The Sukup Bucket Elevator includes robust construction elements such as UHMW seals on all shafts, durable rubber belting, and heavy-gauge trunking. Additional features include the convenience of a large head service platform, a variety of liner options to best suit specific requirements, patented squaring plates and alignment pins for precise assembly, and the strength of welded head and boot frames. These features enhance durability and promote long-term performance. Additionally, the Sukup Bucket Elevator offers a range of optional features to enhance functionality and meet specific needs.
Standard Features
- Up to 60,000 BPH capacity range
- Rubber belting works in all climates
- Patented alignment pins on squaring plates ensure a straight-on connection before leg sections are bolted together (U.S. Patent #8,668,079)
- Optional boot pulleys for various commodities
- Low profile head design for gentle discharge of grain
- Robot, fixture welded trunking for consistent square and parallel construction
- No. 3 vented buckets are standard
Boot Features
- Heavy structural frame
- Acme screw take-up
- Large clean-out doors
- Easy, tool-free access door
- Drip/rain guard to minimize water running into bottom of boot
- Smooth, crown-faced boot pulley
Head Features
- Large work platforms
- Split hood allows for easy interior accessibility without having to completely remove the hood
- Externally-mounted, heavy-duty pillow block roller bearings on head with easy adjustability with standard adjustment bolts
- Heavy-duty, crowned face, slide lagged head pulley
- Static conductive, oil resistant and fire retardant (SOFR) rubber belting standard
- Turned, ground and polished shaft
- Corrosion-resistant Acme thread take-up screws at boot
- High-density, non-sparking, polyethylene buckets
PRODUCT ACCESSORIES
- Liner packages available-urethane, high-energy urethane, ceramic, kryptane
- Optional gravity take-up
- Nylon, urethane, and steel buckets are optional when moving highly abrasive materials
- No. 4 vented buckets available
- Pressure relief door, standard on 36" and larger head section
- Winged pulley is a great option if you are concerned about material collecting on the pulley face
- Herringbone spiral winged pulley runs more quietly than a winged pulley
- Head service platform - One of the largest in the industry available in 3 different sizes
- Distributor platform available in 4'x8'
- Standard, flared, or 45 degree inlets available
- Explosion panels available, check local NFPA requirements
Product Features
- Low Impact Head Design for Better Grain Quality
- Squaring Plates for Efficient Assembly & Increased Strength
- Welded Frames on Head & Boot Sections
